Camera |
|
Image Sensor | 1/2.8" CMOS |
Signal System | PAL/NTSC |
Min. Illumination | Color: 0.0008Lux@ (F1.6, AGC ON), B/W: 0Lux with IR |
Shutter Time | 1s to 1/100,000s |
Day & Night | Dual IR Cut Filter with Auto Switch |
Wide Dynamic Range | Digital WDR |
Angle Adjustment | pan 0~340°, tilt 0~75°, roate 0~360° |
Lens |
|
Lens Type | Fixed |
Focus | 2.8mm |
Lens Mount | M12 |
Aperture | F1.6, Fixed |
FOV | Horizontal field of view: 99.7° |
Illuminator |
|
IR LEDs | 2 |
IR Range | Up to 30m |
Wavelength | 850nm |
White LEDs/Warmlights | N/A |
Compression Standard |
|
Video Compression | S+265/H.265/H.264 |
Video Bit Rate | 32Kbps~6Mbps |
Audio Compression | G.711/G.711U/ADPCM |
Audio Bit Rate | 8K~48Kbps |
Image |
|
Max. Resolution | 1920x1080 |
Main Stream | PAL: 25fps (1920×1080, 1280×720, 704×576, 640×480) |
NTSC: 30fps (1920×1080,1280×720, 704×480, 640×480) |
Sub Stream | PAL: 25fps (704×576, 704×288, 640×360, 352×288) |
NTSC: 30fps (704×480, 704×240, 640×360, 352×240) |
Third Stream | N/A |
Image Setting | Saturation, brightness, contrast, sharpness, adjustable by client software or web browser |
Image Enhancement | BLC/3D DNR/HLC |
ROI | N/A |
OSD | 16×16, 32×32, 48×48, adaptable size, Letters Such as Week, Date, Time, Total 3 Regions |
Picture Overlay | N/A |
Privacy Mask | Yes, 4 regions |
Smart Defog | Yes |
Feature |
|
Alarm Trigger | Motion Detection, Mask Alarm, IP Address Conflict |
Video Analytics | Tripwire, Perimeter |
Early Warning(EW) | N/A |
Network |
|
ANR | N/A
|
Protocols | TCP/IP, HTTP, FTP, DHCP, DNS, DDNS, IPV4, NTP, UDP, Telnet, ICMP, RTP, RTSP, UPnP |
System Compatibility | ONVIF (PROFILE S/T/G), SDK, P2P(Mutually exclusive with Profile G) |
Remote Connection | ≤7 |
Client | Easy7, EasyLive |
Web Version | Web5 |
Interface |
|
Communication Interface | 1 RJ45 10M/ 100M self adaptive Ethernet port |
Audio I/O | Mic in |
Alarm I/O | N/A |
Reset Button | Yes |
On-board storage | Built-in MicroSD card slot, up to 512 GB |
General |
|
Firmware Version | - |
Web Client Language | 15 languages English, Russian, Spanish, Korean, Italian, Turkish, Simple Chinese, Traditional Chinese, Thai, French, Polish, Dutch, Hebraism, Arabic, Vietnamese |
Operating Conditions | -40℃～65℃, 0～95% RH |
Power Supply | DC 12V±25%, PoE (802.3af) |
Power Consumption | MAX: 6W (12V) MAX: 7W (PoE) |
Protection | IP67, Lightning protection, surge protection and voltage transient protection meets EN 55035:2017 |
Heater | N/A |
Dimensions | Φ116.6×83.7mm (Φ4.59×3.30inch) |
Weight | Metal+Plastic: 0.3Kg (0.66lb) Metal: 0.45Kg (0.99lb) |
